REVIEW: NEC LCD2170NX-BK

Warranty LCD/Backlight (Years): 3/3 incl. Pickup Service Max. pixel faults (according to ISO 13406-2): Class II Panel size: 21,3" Pixel size [mm]: 0,270 Native resolution: 1.600 x 1.200 Visible screen size/diagonal [mm]: 432 x 324 / 540 Video-In, connector: D-Sub analog / DVI-D digital Vertical frequency [Hz]: 56 - 85 Max. horizontal frequency/ video bandwidth [kHz/MHz]: 31,5 - 91,1 / - Color mode preset/user: 2 / 4 LCD pivotable / portrait mode: Yes / No LCD display arm option: Yes Features: DVI-D cable, Sub-D cable, USB cable, internal power supply unit, power cable Dimensions (W x H x D) [mm]: 466 x 397,7 – 507,7 x 220 Weight [kg]: 9,2 Compliance: TCO03, ISO 13406-2, MPR II, MPR III, CE, EnergyStar, TUEV GS, TÜV Ergonomics Power consumption On/Stand-by/Off [Watt]: 53 / 0,7 / 0,4 Test date: 19.03.2006 Rating:   Picture stability: ++ (digital) ++ (analog) Viewing angle dependency: ++ Contrast: ++ Color space: ++ Subjective impression of image quality: ++ Shades of gray resolution: ++ Brightness allocation: + Interpolation image quality: + Fabrication of case/frame, mechanics: ++ Operating, OSD: ++ Suitable for occasional gamer: ++ Suitable for hardcore gamer: + Suitable for DVD/Video: ++ Price [incl. VAT. in Euros]: 810,00

++ very good, + good, +/- satisfactory, - bad, -- very bad

Introduction

The NEC 2170NX-BK is targeted towards users with high demands. It comes with the "new" design of the NX range which had been introduced at CeBIT 2005 for the first time. The display's diagonal size is 21,3 inches offering a native resolution of 1.600 x 1.200 pixels. NEC is renowned for its displays being functional and of high quality. In this review, we want to determine where the NEC MultiSync 2170NX-BK ranks in everyday tasks such as working, gaming, and DVD playback.

All results issued in this review have been established using the digital input. The analog input was merely used for testing the analog image quality. Our test bed ran with a Gainward PowerPack! Ultra/2600 Golden Sample graphics card and two Point of View GeForce 7800GTX 512MB (SLI) graphics cards.

Scope of supply

The NEC MultiSync 2170NX-BK's scope of supply includes the following items: one manual with quick instructions, one information sheet about the screen manager software "NaViSet", one sheet with support contact addresses and telephone numbers, one CD, one DVI-D cable (digital), one D-Sub cable (analog), one USB cable, and one power cable. The CD contains monitor drivers for Windows, and a detailed manual in PDF format, the Adobe Reader software and the screen manager software NaViSet. While the setup guide is supplied in several languages, there is no detailed user manual available in printed form, which is unfortunately common practice among manufacturers nowadays. Overall, the scope of supply of the NEC MultiSync 2170NX-BK can be regarded as complete.

Scope of supply of the NEC MultiSync 2170NX-BK

Contents:IntroductionScope of SupplyDesign and mechanicsConnectorsControls and OSDScreenmanagerImage qualityResponsivenessDVD/VideoConclusion
