REVIEW: Asus VW223B

Warranty LCD/Backlight (Years): 3 incl. Pickup Service
Max. pixel faults (according to ISO 13406-2): Class II
Panel size [inch]: 22
Pixel size [mm]: 0,282
Native resolution: 1.680 x 1.050
Visible screen size/diagonal [mm]: 476 x 298 / 565
Video-In, connector: 1 x D-Sub (analogue)
Vertical frequency [Hz]: 56 - 75 (native resolution @ 60 Hz)
Max. horizontal frequency/ video bandwidth [kHz/MHz]: max. 75 kHz / 146 MHz
Color mode preset/user: 5 / 1
LCD pivotable / portrait mode: No / No
LCD display arm option: Yes
Features: Power cable, D-Sub cable, USB cable, 3-port USB 2.0 hub, 1 x USB 2.0 upstream, Installations guide, driver CD
Dimensions (W x H x D) [mm]: 511 x 402 x 210 (with feet)
Weight [kg]: 4,8
Compliance: TCO'03, ISO 13406 Part 2, Energy Star
Power consumption On/Stand-by/Off [Watt]: max. 42 / 1,9 / 0,5
Test date: 8/4/2008
Rating:
Picture stability: +/- (digital USB) +/- (analog VGA)
Viewing angle dependency: +/-
Contrast: +
Color space: +
Subjective impression of image quality: +
Shades of gray resolution: +
Brightness allocation: -
Interpolation image quality: +/-
Fabrication of case/frame, mechanics: - *
Operating, OSD: +
Suitable for occasional gamer: +
Suitable for hardcore gamer: +/-
Suitable for DVD/Video: VGA: HD + / SD +/-; USB: HD -- / SD: --
Price [incl. VAT. in Euros]: 230,00

++ very good, + good, +/- satisfactory, - bad, -- very bad

* The high-frequency oprtational noise caused the model to lose marks . The manufacturing quality of the exterior is good (+).

Introduction

Taiwanese electronics company Asus (AsusTeK Computer Inc.) is certainly a concept known to every PC owner. As well as mainboards, graphics cards, PDAs and laptops (recently also netbooks such as the Asus EEE PC), the company also produces LCD flat screens.

With the Asus VW223B, the company is bringing a model to the market which comes with an integrated graphics chip and can be connected to the PC directly via USB, without the need for a graphics card. In addition, it is possible to connect up to six of these monitors in a row thanks to Asus EzLink software, which manages all models. In order to be able to assess the features of the VW223B, we procured two test samples.

The monitors were tested on both an Asus GeForce 8600 GTS and on an nForce 6190 onBoard Chip.

Scope of supply

The monitor’s packaging has a practical handle on top for carrying. This means that if you buy the monitor directly, you can easily carry it without a car. Weighing a total of 6,6 kg, the monitor can certainly be transported on foot as long as you don’t have too far to walk.

As well as the equipment pictured above (VGA cable, USB cable, manual, driver CD, power cable), the base is included separately within the box and this reduces the size of the packaging enormously. In order to guarantee fast and easy initial use of the monitor, a manual is included. This is multi-lingual and well laid out. Because of the simplicity of the process, however, you can manage very well without the manual.

The driver CD does not contain any monitor profiles. However, it does include the set-up data for the USB transfer software.
