REVIEW: ViewSonic VP2330wb

Warranty LCD/Backlight (Years): 3/3 incl. Pickup Service Max. pixel faults (according to ISO 13406-2): Class II Panel size: 19" Pixel size [mm]: 0,258 Native resolution: 1.920 x 1.200 Visible screen size/diagonal [mm]: 495 x 309 / 584 Video-In, connector: D-Sub analog / DVI-I analog & digital Vertical frequency [Hz]: 24 – 85 analog / 30 – 85 digital Max. horizontal frequency/ video bandwidth [kHz/MHz]: 24 – 96 analog & digital / 165 Color mode preset/user: 6 / 1 LCD pivotable / portrait mode: Yes / Yes LCD display arm option: Yes Features: Sub-D cable, DVI-D cable, USB cable, USB cable, screen manager software, 4-port UDB hub, external power supply unit, power cable Dimensions (W x H x D) [mm]: 542 x 404-539 x 295 (panel aligned to landscape mode) Weight [kg]: 9 Compliance: TCO99, TUEV/GS, TUEV/Ergo, ISO 13406-2, (pixel fault class II), TUEV-S, UL, cUL, FCC-B (ICES), CB, CE, ICES-003B, NOM, ENERGY, Energy Star, GOST-R, Hygienic, SASO, KTL/MIC, BSMI, CCC, PSB, C-TICK, WEEE, RoHS Power consumption On/Stand-by/Off [Watt]: 84,6 / 2,0 / 1,7 Test date: 05.08.2006 Rating:   Picture stability: ++ (digital) ++ (analog) Viewing angle dependency: + Contrast: + Color space: ++ Subjective impression of image quality: ++ Shades of gray resolution: ++ Brightness allocation: + Interpolation image quality: ++ Fabrication of case/frame, mechanics: ++ Operating, OSD: ++ Suitable for occasional gamer: + Suitable for hardcore gamer: +/- Suitable for DVD/Video: ++ Price [incl. VAT. in Euros]: 1400,00

++ very good, + good, +/- satisfactory, - bad, -- very bad

Introduction

The 23 inch widescreen monitor ViewSonic VP2330wb sets out to replace its - already very good - predecessor model VP231wb. Judging from the list of features and the native resolution of 1.920 x 1.200, this display seems to be targeted towards professional users with higher demands. While the previous model, the VP231wb, incorporates an S-IPS panel, the VP2330wb is fitted with an S-MVA panel.

A new display featuring a new Panel - thus, in the light of the predecessor's performance, our expectations of the VP2330wb are accordingly high. In today's review we will provide some insight as to whether this monitor is able to match or even outdo its older brother.

All results issued in this review have been established using the digital input. The analog connection merely has been used to test analog image quality. All tests have been conducted using two Point of View GeForce 7800GTX 512MB (SLI) graphics cards.

Scope of supply

The scope of supply of the ViewSonic VP2330wb is complete, comprising two CDs, one external power supply unit plus one power cable, one D-Sub cable (analog), one DVI-D cable (digital) and one USB cable.

One of the CDs contains the PerfectSuite screen manager software, while the other one holds Windows monitor drivers, a detailed manual in PDF format, as well as the Adobe Reader software.

Scope of Supply of the VP2330wb

Contents:IntroductionScope of SupplyDesign and mechanicsConnectorsControls and OSDImage qualityResponsivenessDVD/VideoConclusion
